Picture of 1269 SWIVEL MALE ELBOW 90° IMPERIAL

1269 SWIVEL MALE ELBOW 90° IMPERIAL

Push-to-connect 90° Swivel Elbow Adaptor with a male BSPT thread. The body is nickel-plated brass with a POM plastic collett and it has a stainless-steel release sleeve for instant tube connection.

One-touch push-to-connect for easy installation
Pre applied sealant on external thread
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C
Swivel Body for easy installation

Overview

One-touch push-to-connect for easy installation
Pre applied sealant on external thread
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C
Swivel Body for easy installation

Item No	Description	Tube Od	Pipe Thread(Male)	U.O.M	Price	Qty	Add to Favourites	Add to cart
PF12690402	1269 1/4 x 1/8 BSPT MALE SWIVEL ELBOW (PL 1/4-01)	1/4"	1/8" BSPT	EACH	$4.81
PF12690404	1269 1/4 x 1/4 BSPT MALE SWIVEL ELBOW (PL 1/4-02)	1/4"	1/4" BSPT	EACH	$5.00
PF12690502	1269 5/16 x 1/8 BSPT MALE SWIVEL ELBOW (PL 5/16-01)	5/16"	1/8" BSPT	EACH	$5.12
PF12690504	1269 5/16 x 1/4 BSPT MALE SWIVEL ELBOW (PL 5/16-02)	5/16"	1/4" BSPT	EACH	$5.44
PF12690506	1269 5/16 x 3/8 BSPT MALE SWIVEL ELBOW (PL 5/16-03)	5/16"	3/8" BSPT	EACH	$6.08
PF12690602	1269 3/8 x 1/8 BSPT MALE SWIVEL ELBOW (PL 3/8-01)	3/8"	1/8" BSPT	EACH	$6.97
PF12690604	1269 3/8 x 1/4 BSPT MALE SWIVEL ELBOW (PL 3/8-02)	3/8"	1/4" BSPT	EACH	$7.30
PF12690606	1269 3/8 x 3/8 BSPT MALE SWIVEL ELBOW (PL 3/8-03)	3/8"	3/8" BSPT	EACH	$7.36
PF12690804	1269 1/2 x 1/4 BSPT MALE SWIVEL ELBOW (PL 1/2-02)	1/2"	1/4" BSPT	EACH	$8.65
PF12690806	1269 1/2 x 3/8 BSPT MALE SWIVEL ELBOW (PL 1/2-03)	1/2"	3/8" BSPT	EACH	$8.96
PF12690808	1269 1/2 x 1/2 BSPT MALE SWIVEL ELBOW (PL 1/2-04)	1/2"	1/2" BSPT	EACH	$10.95
