Picture of 1568 MALE CONNECTOR METRIC

1568 MALE CONNECTOR METRIC

Push-to-connect adaptor with a male BSPT thread. The body is nickel-plated brass with a POM plastic collet and it has a stainless-steel release sleeve for instant tube connection.

Manufacturer: CDC

One-touch push-to-connect for easy installation
Pre applied sealant on external thread
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C

Overview

One-touch push-to-connect for easy installation
Pre applied sealant on external thread
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C

Qty	Add to cart	Price	U.O.M	Item No	Description	Tube Od	Pipe Thread(Male)	Add to Favourites
		$3.81	EACH	PF15680402	1568 4mm x 1/8 BSPT MALE CONNECTOR (PC 04-01)	4MM	1/8" BSPT
		$4.26	EACH	PF15680404	1568 4mm x 1/4 BSPT MALE CONNECTOR (PC 040-02)	4MM	1/4" BSPT
		$4.03	EACH	PF15680602	1568 6mm x 1/8 BSPT MALE CONNECTOR (PC 06-01)	6MM	1/8" BSPT
		$4.26	EACH	PF15680604	1568 6mm x 1/4 BSPT MALE CONNECTOR (PC 06-02)	6MM	1/4" BSPT
		$4.84	EACH	PF15680802	1568 8mm x 1/8 BSPT MALE CONNECTOR (PC 08-01)	8MM	1/8" BSPT
		$4.91	EACH	PF15680804	1568 8mm x 1/4 BSPT MALE CONNECTOR (PC 08-02)	8MM	1/4" BSPT
		$5.64	EACH	PF15680806	1568 8mm x 3/8 BSPT MALE CONNECTOR (PC 08-03)	8MM	3/8" BSPT
		$6.23	EACH	PF15681002	1568 10mm x 1/8 BSPT MALE CONNECTOR (PC 10-01)	10MM	1/8" BSPT
		$5.93	EACH	PF15681004	1568 10mm x 1/4 BSPT MALE CONNECTOR (PC 10-02)	10MM	1/4" BSPT
		$6.14	EACH	PF15681006	1568 10mm x 3/8 BSPT MALE CONNECTOR (PC 10-03)	10MM	3/8" BSPT
		$9.45	EACH	PF15681008	1568 10mm x 1/2 BSPT MALE CONNECTOR (PC 10-04)	10MM	1/2" BSPT
		$8.07	EACH	PF15681204	1568 12mm x 1/4 BSPT MALE CONNECTOR (PC 12-02)	12MM	1/4" BSPT
		$8.42	EACH	PF15681206	1568 12mm x 3/8 BSPT MALE CONNECTOR (PC 12-03)	12MM	3/8" BSPT
		$10.33	EACH	PF15681208	1568 12mm x 1/2 BSPT MALE CONNECTOR (PC 12-04)	12MM	1/2" BSPT
		$20.88	EACH	PF15681606	1568 16mm x 3/8 BSPT MALE CONNECTOR (PC 16-03)	16MM	3/8" BSPT
		$20.88	EACH	PF15681608	1568 16mm x 1/2 BSPT MALE CONNECTOR (PC 16-04)	16MM	1/2" BSPT
