NP1569 SWIVEL MALE ELBOW 90° METRIC - PARALLEL THREAD

Push-to-connect 90° Swivel Elbow Adaptor adaptor with a male BSPP thread and o'ring seal. Made of Nickel-plated brass this fitting offers anti-contamination properties which ensures an extended product life.

Manufacturer: API

One-touch push-to-connect for easy installation
O'Ring Seal
For use on air and water
Working pressure, 0-150psi
Working Temperature 0-80°C
Swivel Body for easy installation

Overview

One-touch push-to-connect for easy installation
O'Ring Seal
For use on air and water
Working pressure, 0-150psi
Working Temperature 0-80°C
Swivel Body for easy installation

Item No	Description	Tube Od	Pipe Thread(Male)	U.O.M	Price
PFNP15690402	NP1569 4mm x 1/8 BSPP MALE SWIVEL ELBOW N.P	4MM	1/8" BSPP	EACH	$10.70
PFNP15690404	NP1569 4mm x 1/4 BSPP MALE SWIVEL ELBOW N.P	4MM	1/4" BSPP	EACH	$11.20
PFNP15690602	NP1569 6mm x 1/8 BSPP MALE SWIVEL ELBOW N.P	6MM	1/8" BSPP	EACH	$10.70
PFNP15690604	NP1569 6mm x 1/4 BSPP MALE SWIVEL ELBOW N.P	6MM	1/4" BSPP	EACH	$11.20
PFNP15690605	NP1569 6mm x M5 MALE SWIVEL ELBOW N.P	6MM	M5	EACH	$10.56
PFNP15690802	NP1569 8mm x 1/8 BSPP MALE SWIVEL ELBOW N.P	8MM	1/8" BSPP	EACH	$12.48
PFNP15690804	NP1569 8mm x 1/4 BSPP MALE SWIVEL ELBOW N.P	8MM	1/4" BSPP	EACH	$13.00
PFNP15690806	NP1569 8mm x 3/8 BSPP MALE SWIVEL ELBOW N.P	8MM	3/8" BSPP	EACH	$18.56
PFNP15691004	NP1569 10mm x 1/4 BSPP MALE SWIVEL ELBOW N.P	10MM	1/4" BSPP	EACH	$17.28
PFNP15691006	NP1569 10mm x 3/8 BSPP MALE SWIVEL ELBOW N.P	10MM	3/8" BSPP	EACH	$18.56
PFNP15691204	NP1569 12mm x 1/4 BSPP MALE SWIVEL ELBOW N.P	12MM	1/4" BSPP	EACH	$21.70
PFNP15691206	NP1569 12mm x 3/8 BSPP MALE SWIVEL ELBOW N.P	12MM	3/8" BSPP	EACH	$21.70
