P1569 MALE ELBOW MALE 90° METRIC - METRIC THREAD

Push-to-connect 90° Swivel Elbow adaptor with a male BSPP thread and o'ring seal. The body is nickel-plated brass with a POM plastic collet and it has a stainless-steel release sleeve for instant tube connection.

Manufacturer: CDC

One-touch push-to-connect for easy installation
O'Ring seal
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C
Swivel Body for easy installation

Overview

One-touch push-to-connect for easy installation
O'Ring seal
For use on AIR ONLY
Working pressure, 0-150psi
Working Temperature 0-60°C
Swivel Body for easy installation

Price (Excl. G.S.T)	U.O.M	Item No	Description	Tube Od	Pipe Thread(Male)
$4.64	EACH	PFP15690402	P1569 4mm x 1/8 BSPP MALE SWIVEL ELBOW (PL 04-G01)	4MM	1/8" BSPP
$4.90	EACH	PFP15690404	P1569 4mm x 1/4 BSPP MALE SWIVEL ELBOW (PL 04-G02)	4MM	1/4" BSPP
$4.72	EACH	PFP15690405	P1569 4mm x M5 MALE SWIVEL ELBOW (PL 04-M5)	4MM	5MM
$6.93	EACH	PFP15690406	P1569 4mm x M6 MALE SWIVEL ELBOW (PL 04-M6)	4MM	M6
$4.64	EACH	PFP15690602	P1569 6mm x 1/8 BSPP MALE SWIVEL ELBOW (PL 06-G01)	6MM	1/8" BSPP
$5.04	EACH	PFP15690604	P1569 6mm x 1/4 BSPP MALE SWIVEL ELBOW (PL 06-G02)	6MM	1/4" BSPP
$5.54	EACH	PFP15690605	P1569 6mm x M5 MALE SWIVEL ELBOW (PL 06-M5)	6MM	5MM
$5.42	EACH	PFP15690802	P1569 8mm x 1/8 BSPP MALE SWIVEL ELBOW (PL 08-G01)	8MM	1/8" BSPP
$5.73	EACH	PFP15690804	P1569 8mm x 1/4 BSPP MALE SWIVEL ELBOW (PL 08-G02)	8MM	1/4" BSPP
$6.38	EACH	PFP15690806	P1569 8mm x 3/8 BSPP MALE SWIVEL ELBOW (PL 08-G03)	8MM	3/8" BSPP
$7.27	EACH	PFP15691004	P1569 10mm x 1/4 BSPP MALE SWIVEL ELBOW (PL 10-G02)	10MM	1/4" BSPP
$7.40	EACH	PFP15691006	P1569 10mm x 3/8 BSPP MALE SWIVEL ELBOW (PL 10G-03)	10MM	3/8" BSPP
$8.67	EACH	PFP15691204	P1569 12mm x 1/4 BSPP MALE SWIVEL ELBOW (PL 12- G02)	12MM	1/4" BSPP
$8.91	EACH	PFP15691206	P1569 12mm x 3/8 BSPP MALE SWIVEL ELBOW (PL 12-G03)	12MM	3/8" BSPP
